MPP Series | MPP 100/250/400/630VDC

Metallized Polyester Film Capacitor

MPP Series | MPP 100/250/400/630VDC

Metallized Polypropylene Film Capacitor

产品特征

*PP材质，损耗低

产品特色&性能及应用领域

*适用在降压回路上

*常用于高稳定性的滤波回路上

*一般电子回路


产品说明

Capacitor Range : 0.001uF~10uF

Rated Voltages :100/250/400/630VDC

Tolerance : J(±5%),K(±10%),M(±20%)

Temperature range : -40°C ~ +105°C

Dissipation Factor(DF) :<=0.1% max. (at20˚C,1KHz)


规格说明
