MEM (MINI BOX) Series | MEM 63/100/250/400/630VDC

Metallized Polyester Film Capacitor

MEM (MINI BOX) Series | MEM 63/100/250/400/630VDC

Metallized Polyester Miniature size

产品特征

*小型化盒裝產品

*體積極小,腳距達5mm

產品特色&效能及應用領域

*適用於一般電子迴路

*小體積迴路產品布局


产品说明

Capacitor Range : 0.001uF~1.2uF

Rated Voltages :63/100/250/400/630VDC

Tolerance : J(±5%),K(±10%)

Temperature range : -40°C ~ +105°C

Dissipation Factor(DF) :<=1.0% max. (at20˚C,1KHz)


规格说明
